General Information
Internal Identifier leuther
| Soil Type | Luvisol |
|---|
| Classification | WRB |
|---|
|
| Location | Rehovot |
|---|
| Latitude | 31.900 |
|---|
| Longitude | 34.850 |
|---|
|
| Landuse | orchard |
|---|
| Tillage | No tillage |
|---|
| Crop | grapefruit |
|---|
|
| Sampling Depth | 5.0 |
|---|
| Sample Height | 10.0 |
|---|
| Sampling Date | Feb. 15, 2016 |
|---|
| Voxel size | 0.019 |
|---|
| Pores white? | True |
|---|
|
| XY Plane |
|
|---|
|
| XY Plane Grey |
|
|---|
|
| Texture | loamy sand |
|---|
| Sand | 90.0 |
|---|
| Silt | 5.0 |
|---|
| Clay | 5.0 |
|---|
|
|
Results
| Porosity | Surface | Mean Curvature | Euler | MeanPoreSize | Gamma | PoreDist |
| 0.432205099 | 13.224622232 | 17.696564011 | 3.431974375 | 0.174930227879 | 0.9393818881 | 0.049805639 |
| Opening size | Volume | Surface | MeanCurvature | Euler number |
|---|
| 0.038 | 0.432205099 | 13.224622232 | 17.696564011 | 3.431974375 |
| 0.0475 | 0.410958373 | 11.325875066 | 13.228583987 | -4.874171349 |
| 0.057 | 0.391214332 | 10.192643489 | 11.208382212 | -0.675536543 |
| 0.0665 | 0.374032479 | 9.344515527 | 10.01344546 | 8.25735498 |
| 0.076 | 0.363529959 | 8.869993882 | 9.767289291 | 19.917744727 |
| 0.0855 | 0.306700505 | 6.571932774 | 6.392156916 | 13.466723519 |
| 0.095 | 0.281815718 | 5.691242915 | 5.303965114 | 12.405644435 |
| 0.114 | 0.250843792 | 4.637152955 | 4.12524726 | 10.940487111 |
| 0.133 | 0.199431077 | 3.118036173 | 2.296810351 | 5.376429001 |
| 0.152 | 0.174008836 | 2.477595595 | 1.641501429 | 3.418820008 |
| 0.171 | 0.143642249 | 1.809167381 | 1.0153003 | 1.871986023 |
| 0.19 | 0.131469345 | 1.570798797 | 0.82464624 | 1.277289045 |
| 0.209 | 0.11102215 | 1.227352646 | 0.585746212 | 0.819995411 |
| 0.228 | 0.101662568 | 1.076448498 | 0.490608852 | 0.553559684 |
| 0.247 | 0.089026042 | 0.906773783 | 0.40306609 | 0.456934879 |
| 0.266 | 0.083301436 | 0.827846453 | 0.362039411 | 0.358037955 |
| 0.285 | 0.072310748 | 0.695236188 | 0.298235785 | 0.297408281 |
| 0.38 | 0.04031052 | 0.348912952 | 0.142721185 | 0.143023846 |
| 0.475 | 0.016268886 | 0.122692248 | 0.046068172 | 0.048551573 |
| 0.57 | 0.006619228 | 0.042204624 | 0.013958296 | 0.013273952 |
| 0.665 | 0.00311569 | 0.016481024 | 0.004705074 | 0.004305066 |
| 0.855 | 0.00144521 | 0.006127322 | 0.001334869 | 0.001076266 |
| 1.045 | 0.000616972 | 0.002244585 | 0.000429771 | 0.00023917 |
| 1.235 | 0.000584281 | 0.002138991 | 0.000415162 | 0.000478341 |
| 1.425 | 0.000520494 | 0.001965395 | 0.000392648 | 0.00023917 |
Reference: An open Soil Structure Library based on X-ray CT data
